| Brand Name: | Wenergy |
| Model Number: | Turtle CL6.25 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | L/C,T/T |
| System Parameters | Specifications |
|---|---|
| Rated Energy | 6.25MWh |
| Max. Efficiency of System | >90% |
| Operating Temp. Range | -30～55℃ (>45℃ Reduction) |
| Operating Humidity Range | ≤95% |
| Auxiliary Power Supply | Self-powered / External-powered |
| Noise | ≤75dB |
| Max. Cycle Times | ≥8000 |
| Max. Working Altitude | 4000m (Greater than 2000m Reduction) |
| Cooling Type | Intelligent Liquid Cooling |
| Fire Safety Configuration | Pack & Cluster-level Aerosol, Cluster-level Water Fire Protection & Active Warning |
| Protection Level | IP55 |
| Communication Interface | RS485/CAN |
| DC Parameters | Specifications |
| Communication Protocol | Modbus TCP/CAN2.0 |
| Battery Type | LFP 3.2V/587Ah |
| Battery Packing Method | 8*1P416S |
| DC Voltage Range | 1164.8～1497.6 |
| Mechanical Parameters | Specifications |
| DC Protection | Contactor+Fuse |
| Dimension (W*D*H) | 6058*2438*2896mm |
| Weight | ≈52T |
