| Brand Name: | wenergy |
| Model Number: | 48V20Ah |
| MOQ: | 10 |
| Price: | Negotiable |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 3000 sets per month |
| Parameter | Specification |
|---|---|
| Voltage Range | 39V - 54.6V (48V nominal) |
| System Energy (23±2℃, 1/3C) | 0.96 kWh rated |
| System Capacity (23±2℃, 1/3C) | 20Ah rated |
| Single Cell Model | SEPFe86117169-20Ah |
| Operating Temperature | Discharge: -20°C to 45°C Charge: 0°C to 45°C |
| Environmental Humidity | 10% to 90% relative humidity |
| Storage Temperature | -20°C to 45°C |
| Standard Charging Current | 0.5C |
| Maximum Charging Current | 1C |
| Standard Discharging Current | 0.5C |
| Continuous Discharging Current | 1C |
| Peak Discharge Current (5s) | 3C |
| System Insulation Resistance | ≥20mΩ |
| Insulation Resistance Test | ≥20MΩ |
| Waterproof Rating | IP65 |
| Cooling System | Air cooling |
