| Brand Name: | Wenergy |
| Model Number: | Turtle M Series |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | L/C,T/T |
| Performance Parameter | Unit | 964 kWh | 1,446 kWh | 1,929 kWh |
| Product Name | / | 768 V / 964 kWh Mobile Energy Storage Vehicle | 768 V / 1,446 kWh Mobile Energy Storage Vehicle | 768 V / 1,929 kWh Mobile Energy Storage Vehicle |
| Rated Voltage | V | 768 V | ||
| Operating Voltage Range | V | 672–864 | ||
| Nominal Capacity | Ah | 1,256 | 1,884 | 2,512 |
| Nominal Energy | kWh | 964.608 | 1,446.912 | 1,929.216 |
| Battery Chemistry | / | LiFePO₄ (LFP) | ||
| Discharge Output Interfaces | / | Battery DC; AC 400 V; DC fast-charging output | ||
| Charging Input Interfaces | / | 4 × 250 A DC fast-charging inlets; max. 120 kW per connector; AC 400 V | 4 × 250 A DC fast-charging inlets; max. 160 kW per connector; AC 400 V | 4 × 250 A DC fast-charging inlets; AC 400 V |
| AC Discharge Power | kW | 500 | 750 | 1,000 |
| Isolation Transformer (Optional) | kVA | 500 | 800 | - |
| DC Fast-Charging Output | / | 4 × 120 kW charging connectors | 4 × 160 kW charging connectors | 4 × 240 kW charging connectors |
| Corrosion Protection Class | - | C4 | ||
| Overall Dimensions (L × W × H) | mm | 6,058 × 2,438 × 2,591 | ||
| Energy Storage Compartment Protection Rating | - | IP54 | ||
| Operating Temperature Range | °C | −30 to +55 | ||
| Relative Humidity | RH | 5%–90% | ||
| Maximum Operating Altitude | m | 4,000 (derating above 2,000 m) | ||
| Applications | - | EV charging; construction-site power; optional isolation transformer supports 100% three-phase load imbalance and sensitive equipment | EV charging; construction-site power; balanced three-phase load distribution required without an isolation transformer | |
