| Brand Name: | wenergy |
| Model Number: | 48V20Ah |
| MOQ: | 10 |
| Price: | Negotiable |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 3000 sets per month |
| Parameter | Specification |
|---|---|
| Voltage Range | 39V - 54.75V (48V nominal) |
| System Energy (23±2℃, 1/3C) | 1.152kWh rated |
| System Capacity (23±2℃, 1/3C) | 24Ah rated |
| Operating Temperature | Discharge: -20°C to 45°C Charge: 0°C to 45°C |
| Environmental Humidity | 10% to 90% relative humidity |
| Storage Temperature | -20°C to 45°C |
| Standard Charging Current | 0.5C |
| Maximum Charging Current | 1C |
| Standard Discharging Current | 0.5C |
| Continuous Discharging Current | 30A |
| Peak Discharge Current (5s) | 3C |
| System Insulation Resistance | ≥20mΩ |
| Waterproof Rating | IP67 |
| Max powerTYPE-C | 65W |
| size | 184×156×280mm |
True 1kWh Capacity, Fully Verifiable
Guaranteed real capacity with on-site testing and discharge verification.
Certified Safety & Automotive-Grade Reliability
3C certified, UN38.3 approved, drop & vibration tested for maximum safety.
100% New Grade-A LiFePO4 Cells
Built with brand-new automotive-grade cells, no used or downgraded cells.
High Energy & Long Cycle Life
1200Wh energy, 48V system, 2000+ cycles for long-term durability.
Multi-Scenario Power Solution
Suitable for outdoor power, electric motorcycles, camping, and emergency backup.
Smart Monitoring & Anti-Theft Tracking
Real-time battery data, 4G connectivity, dual Beidou + GPS positioning.
Compact & Lightweight Design
Only 9kg with 18% reduced size, easy to carry and install.
Reliable After-Sales Support
Free warranty repair and lifetime cost-price service.
